4" Garrett Traction Engine Steel Boiler. Professional made by AJB Engineering, Anthony (Tony) John Baldwin in Ripley. Tony Baldwin is CE approved and this boiler, unused and dry stored, was independently tested by the then Peter Cole of Royal & Sun Alliance (RSA). RSA are now British Engineer Services. We have the certification, that Tony kindly copied and sent to us.

Based on the drawings from Bob Whitehead, castings I understand available from AN (Adrian Nutting) Engineering.

Boiler Dimensions are 36 3/4" total length, 10" diameter main tube, 13 7/8" x 10" outside dimensions of base by foundation ring and 7 1/2" x 11 1/8" inside firebox. Coal opening is 3" x 4". Main material used is 10mm thickness.

This boiler would now cost £2600 from AJB Engineering.

Certificates shown above. Design pressure 10.34 Bar, test pressure 18.3 Bar, mains water at 10 degrees C, for 30 min.



Price:  £1,985 (No additional VAT to add)

Happy to consider a loco, traction, or stationary/marine/aero engines as a part exchange.

Click here to go back to 'Steam Engine' Menu



Call Howard on 01225 812155 or 07753 610420
Alternatively email:   sales@myford-lathes.com
